To load a sheet with the roll-feed option installed
From time to time you may want to load a separate sheet even though you
normally use a roll—for example, to use the Setup Sheet.
1 If a roll is currently loaded in the printer, unload it as explained on page 2–16, step
2a—c, remembering to raise the media lever again when it’s done.
2 On the front panel, make sure the
Sheet light is on, to indicate that you are going
to load a sheet.
3 Load the sheet as explained starting with step 4 on page 2–10.
Localization Note.
Working with media
To load a sheet with the roll-feed option installed
SHEET
MEDIA SOURCE
This is the green on page 2–24
(seq: 66)
