HP Designjet 4500

4-75
Service Tests and Utilities
HP Designjet 4500 Printer Series Service Manual
4 Use the Arrow keys to scroll to the "Service Utilities" menu and press the
Enter key.
5 Use the Arrow keys to scroll through the "Service Utilities" selections and
press the Enter key to begin a specific operation when the required Service
Utility is highlighted.
If the printer is not used for 135 seconds, the printer exits out
of the Service Utilities Menu and you must repeat the above
steps to enter Service Utilities again.
In some cases a quick press of a button may not be
recognized by the Printer. When pressing a button, be sure to
press it deliberately and all the way to the bottom of its
travel.
Press Enter to
confirm selection
Use UP and
DOWN keys
to select
Press Enter to
confirm selection
Use UP and
DOWN keys
to select
