2-5
System Error Codes
HP Designjet 4500 Printer Series Service Manual
Replace the Carriage PCA ⇒ Page 8-55.
If the System Error continues, replace the Gamut PCI PCA ⇒ Page 8-76.
System Error:
03:10
Problem
Description:
Problem with the Power Supply Unit.
Corrective Action:
Try the following:
Switch the Power OFF from the back of the Printer and disconnect the
Power cord. Reconnect the power cord and power On the Printer.
Perform the Electronics Modules Test (⇒ Page 4-28) to troubleshoot the
problem further.
If the System Error continues, replace the Power Supply Unit ⇒ Page 8-
85.
System Error:
05.1:10
Problem
Description:
CPU Fan is stopped or burnt.
Corrective Action:
Try the following:
Switch the Power OFF from the back of the Printer and disconnect the
Power cord. Reconnect the power cord and power On the Printer.
Replace the CPU Fan ⇒
Page 8-83
.
If the System Error continues, r
eplace
the Main PCA ⇒ Page 8-81.
System Error:
05.3:10
Problem
Description:
Main memory size failure.
Corrective Action:
Try the following:
Check that at least 256 megabytes of memory is installed in the Printer.
Check that the Memory Module is installed correctly.
Try installing the Memory Module in the other Memory slot and check if
the System Error appears.
If the System Error reappears, r
eplace
the Memory Module ⇒ Page 8-79.
If the System Error does NOT reappear, then the original slot could be
faulty. In this case, replace the Main PCA ⇒ Page 8-81.
System Error:
06:03
Problem
Description:
NVM file has bad CRC.
Corrective Action:
Try the following:
Switch the Power OFF from the back of the Printer and disconnect the
Power cord. Reconnect the power cord and power On the Printer.
If the System Error continues, replace the Hard Disk Drive ⇒ Page 8-83.
