Single Sheet Load Sensor
Removal
Switch off the product and remove the power cable.
1. Remove Output Platen
⇒ Page 8-104 .
2. Open the Roll 1 Drawer.
3. Press down to release the Right Roll 1
Locking Lever.
4. Press down to release the Left Roll 1
Locking Lever.
