HP Designjet 4500 - Page 525

8-225
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
7. Disconnect two cables from the BT Arm
Encoder Disc PCA.
8. Remove two T-8 screws (Type L) that
secure the BT Arm Encoder Disc PCA.
9. Remove the BT Arm Encoder Disc PCA.
