8-284
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
9. Disconnect the Heating Lamp Cable on the
right of the chassis, push in the retaining
clip with a screw driver and release the
cable.
10. Remove the Heating Lamp Cable.
11. Remove two screws that secure the Right
Heating Lamp Cover.
To Next Page
