8-283
Removal and Installation
HP Designjet 4500 Printer Series Service Manual
6. Remove the Left Heating Lamp Cover.
7. Disconnect the Earthing Cable from the left
end of the Heating Lamp.
8. Remove three springs from the left end of
the Heating Lamp.
