6. Remove one T-10 (Type I) screw that secures the ESD Strip to the Top Cover (on the left-hand side
of the printer).
7. Disconnect the ESD Strip from the Top Cover.
8. Remove the three T-15 screws that secure the PW Cover.
NOTE: Each screw includes a washer (part number 3050-1267).
232 Chapter 9 Printer part removal and installation ENWW
