HP DESIGNJET T7100 Monochrome Series - Page 243

9. Remove the PW Cover.
10. Remove four T-15 screws (Type H) that secure the Top Cover from the rear of the printer.
NOTE: Each screw includes a washer (part number 3050-1267).
11. Release the Top Cover from the rear of the printer.
ENWW
Disassembly order
233
