HP Designjet T7100 Series User Manual

HP Designjet T7100 Printer series
Technical specifications
Print
Line Drawings 16 sec/page on A1/D 165 A1 prints per hour
Colour images CQ105A: 117.5 m²/hr on coated media; 11.2 m²/hr on glossy media
Print speed 123.3 m²/hr; Mechanical printing time. Printed in Fast mode on HP Bright White Inkjet Paper
(bond). Speed indicated is maximum printer speed
Print resolution Up to 2400 x 1200 optimized dpi
Margins (top x bottom x left x right) Roll: 5 mm (top), 5 mm (right), 5 mm (left), 5 mm (bottom)
Technology HP Thermal Inkjet
Ink colours 6 (cyan, magenta, yellow, matte black, grey, dark grey)
Print head nozzles 2112
Print heads 8 (2 yellow, 2 magenta and cyan, 2 matte black, 2 grey and dark grey)
Line accuracy +/- 0.1% (+/- 0.1% of the specified vector length or +/- 0.2 mm (whichever greater) at 23º
C,50-60% relative humidity, on A0/E printing material in Best or Normal mode with HP Matte
Film)
Minimum line width 0.02 mm (HP-GL/2 addressable)
Guaranteed minimum line width 0.06 mm (ISO/IEC 13660:2001(E))
Maximum print length 91 m
Media
Handling Two roll feeds (upgradeable to three); automatic roll switching; automatic cutter; media bin
Types Bond and coated paper (bond, coated, recycled, heavyweight coated), technical paper (natural
tracing, translucent bond, vellum), film (clear, matte, polyester), photographic paper (satin, gloss,
semi-gloss, matte, high-gloss), self-adhesive (indoor paper, polypropylene, vinyl), banner and
sign material (backlit, outdoor paper, blue back billboard paper)
Weight 70 to 328 g/m²
Thickness Up to 0.4 mm
Memory
Standard 32 GB, Based on 1 GB RAM, Expandable to 1.5 GB RAM through a Designjet qualified SODIMM
included only in the optional HP Designjet PostScript®/PDF Upgrade Kit accessory
Hard disk Standard, 160 GB
Connectivity
Interfaces (standard) Gigabit Ethernet (1000Base-T); EIO Jetdirect accessory slot; Hi-Speed USB 2.0
Interfaces (optional) Compatible HP Jetdirect LAN cards
Print languages (standard) HP-GL/2, HP-RTL, CALS G4
Print languages (optional) Adobe® PostScript® 3; Adobe® PDF 1.7; TIFF; JPEG
Drivers included HP-GL/2, HP-RTL drivers for Windows® (optimised for AutoCAD 2000 and higher); PostScript®
Windows®, Linux, and Mac drivers with optional PostScript®/PDF Upgrade Kit
Environmental ranges
Operating temperature 5 to 40ºC
Storage temperature -20 to 55ºC
Operating humidity 20 to 80% RH
Storage humidity 20 to 80% RH
Acoustic
Sound Pressure 53 dB(A), 38 dB(A) (standby)
Sound Power 7.0 B(A), 5.8 B(A) (standby)
Dimensions (w x d x h)
Printer 1974 x 700 x 1374 mm
Packaged 2232 x 761 x 1269 mm
Weight
Printer 187 kg
Packaged 220 kg
Power consumption
Maximum 420 watts maximum, 270 watts (active), <100 watts (standby), <9 watts/<46 watts with
embedded Digital Front End (sleep), <0.5 watts (manual off)
Power requirements Input voltage (auto ranging): 100 to 127 VAC (+/- 10%), 5 A; 220 to 240 VAC (+/- 10%), 3 A;
50/60 Hz (+/- 3 Hz)
What's in the box
CQ105A HP Designjet T7100 Printer; printheads; introductory ink cartridges; printer stand; media bin;
762 mm (3-in) spindle adaptor kit (x2); maintenance cartridge; startup software; quick reference
guide; setup poster; power cords
Certification
Safety EU (LVD and EN 60950-1 compliant); Russia (GOST)
Electromagnetic Compliant with Class A requirements EU (EMC Directive)
Environmental ENERGY STAR®; WEEE; EU RoHS; China RoHS; REACH; FEMP
ENERGY STAR Yes
Warranty
Standard warranty: two years, next business day on-site support. Warranty and support options
vary by product, country and local legal requirements.
Ordering information
Product
CQ105A HP Designjet T7100 Printer
Accessories
CQ745A HP Designjet PostScript/PDF Upgrade Kit
CQ742A HP Designjet 220V Stacker
CQ743A HP Designjet Roll Upgrade Kit
Ink supplies
CH649A HP 761 Designjet Maintenance Cartridge
CH645A HP 761 Yellow Designjet Printhead
CH646A HP 761 Magenta/Cyan Designjet Printhead
CH647A HP 761 Gray/Dark Gray Designjet Printhead
CH648A HP 761 Matte Black/Matte Black Designjet Printhead
CM997A HP 761 775-ml Matte Black Designjet Ink Cartridge
CM991A HP 761 400-ml Matte Black Designjet Ink Cartridge
CM992A HP 761 400-ml Yellow Designjet Ink Cartridge
CM993A HP 761 400-ml Magenta Designjet Ink Cartridge
CM994A HP 761 400-ml Cyan Designjet Ink Cartridge
CM995A HP 761 400-ml Gray Designjet Ink Cartridge
CM996A HP 761 400-ml Dark Gray Designjet Ink Cartridge
CR270A HP 761 3-pack 400-ml Yellow Designjet Ink Cartridge
CR271A HP 761 3-pack 400-ml Magenta Designjet Ink Cartridge
CR272A HP 761 3-pack 400-ml Cyan Designjet Ink Cartridge
CR273A HP 761 3-pack 400-ml Gray Designjet Ink Cartridge
CR274A HP 761 3-pack 400-ml Dark Gray Designjet Ink Cartridge
CR275A HP 761 3-pack 775-ml Matte Black Designjet Ink Cartridge
Media supplies
C6036A HP Bright White Inkjet Paper-914 mm x 45.7 m
C6810A HP Bright White Inkjet Paper-914 mm x 91.4 m (36 in x 300 ft)
Q1398A HP Universal Bond Paper-1067 mm x 45.7 m (42 in x 150 ft)
Q8751A HP Universal Bond Paper-914 mm x 175 m (36 in x 574 ft)
Q1414A HP Universal Heavyweight Coated Paper-1067 mm x 30.5 m (42 in x 100 ft)
Q1956A HP Heavyweight Coated Paper-1067 mm x 67.5 m (42 in x 225 ft)
C3875A HP Clear Film-914 mm x 22.9 m (36 in x 75 ft)
51642B HP Matte Film-914 mm x 38.1 m (36 in x 125 ft)
Q8754A HP Universal Instant-dry Gloss Photo Paper-1067 mm x 61 m (42 in x 200 ft)
Q8755A HP Universal Instant-dry Satin Photo Paper-1067 mm x 61 m (42 in x 200 ft)
Q1428A HP Universal Gloss Photo Paper-1067 mm x 30.5 m (42 in x 100 ft)
CH025A HP 2-pack Everyday Matte Polypropylene-1067 mm x 30.5 m (42 in x 100 ft)
Service & support
UX919E HP Care Pack, Next Business Day Designjet T7100 Hardware Support, 3 years
UX923E HP Care Pack, Next Business Day Designjet T7100 Hardware Support, 4 years
UX922E HP Care Pack, Next Business Day Designjet T7100 Hardware Support, 5 years
UX920E HP Care Pack, 4 Hour Response Time 13x5 Designjet T7100 Hardware Support, 3 years
UX933 HP Care Pack, Post Warranty Next Business Day Designjet T7100 Hardware Support, 1 year
UX932 HP Care Pack, Post Warranty Next Business Day Designjet T7100 Hardware Support, 2 years
UX935 HP Care Pack, Post Warranty 4 Hour Response Time 13x5 Designjet T7100 Hardware Support, 1 year
H4518E HP Care Pack, Network Install Designjet T23-71XX, 400-6200 SVC
HP Designjet Support Services offer solutions for business critical environments - installation, extended support
and maintenance, as well as variety of value added services. For more information, please visit
hp.com/go/designjet/support.
Use Original HP inks and printheads to experience consistent high quality and reliable performance that enable
less downtime. For more information, visit hp.com/go/OriginalHPinks.
For the entire HP Large Format Printing Materials portfolio, please see globalBMG.com/hp.
For more HP Large Format Media substrates and sizes please visit us online at: http://www.hp.com/go/designjet/supplies
© Copyright 2014 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
4AA2-6871EEE Published in EMEA April 2014

HP Designjet T7100 Series Specifications

General

Print Technology	Thermal Inkjet
Media Types	Bond and coated paper, technical paper, film, photographic paper, backlit, self-adhesive
Media Sizes	210 to 1067 mm
Connectivity	Gigabit Ethernet (1000Base-T)
Ink Types	Dye-based (C, M, Y)
Print Languages	HP-GL/2, HP-RTL
Operating Systems Supported	Windows, Mac OS X, Linux
Print Speed	Up to 165 A1 prints per hour
Memory	160 GB (hard disk); 32 GB (virtual)
