Diagnostic Tests and Utilities
The following is a list of all diagnostic test and utilities available in the product. For instructions on entering
the Diagnostics menu, see Entering the Diagnostics Menu on page 162.
+ Scan Axis Test on page 162
Star-wheel lifter
PRS
Scan axis
Cutter
Paper Drive Test on page 165
Electronics Module Test on page 166
Carriage Assembly Test on page 167
Sensors Test on page 170
Stacker Empty Sensor Test on page 170
Output Valve Test on page 171
Output Valve Calibration on page 171
Pinches Lifter Test on page 173
Stacker Ramps Test on page 173
Stacker Overdrive Test on page 174
Stacker Jam Sensor Test on page 174
Stacker Capacity Sensor Test on page 174
+ Ink Delivery System (IDS) Test on page 175
Ink Delivery System
Check ink supplies
Check leakage
+ Service Station Test on page 177
Service station
Primers
Enable I/O Interfaces Utility on page 178
Unit Information Utility on page 178
EEROM Reset Utility on page 179
Front Panel Lock Reset on page 179
Hard Disk Recovery on page 179
File System Check on page 179
