Stacker Overdrive Test
Perform the Stacker Overdrive test as follows:
NOTE: Perform this test with the printheads and the tubes system installed in order to get values that can
be correctly compared.
1. In the Diagnostics menu, select Stacker Overdrive.
2. The product starts the Stacker Overdrive PWM control test to check the subsystem. As the test executes
the Front Panel displays the following messages:
●
Initializing
●
Performing movements
If there is a failure at any point during the test, the Front Panel displays the relevant System Error Code.
To troubleshoot any displayed error codes, see System Error Codes.
3. Press OK to end the test and restart the product.
Stacker Jam Sensor Test
This test diagnoses Stacker Jam Sensor failure. Always run this test before replacing the sensor.
Perform the Stacker Jam Sensor test as follows:
1. In the Diagnostics menu, scroll to Stacker Jam Sensor, select it, and press OK to start the test, or Cancel
to exit.
2. The sensor test starts, and the Front Panel prompts you to lift the first wheel holder containing the jam
sensor.
Lift the wheel holder, and press OK to continue.
NOTE: Make sure that no object is interfering with the sensor.
3. The Front Panel prompts you to lower the first wheel holder.
Lower the wheel holder, and press OK to continue.
4. When the test is complete, the Front Panel displays a final message. Press OK to shutdown.
Stacker Capacity Sensor Test
This test diagnoses Stacker Capacity sensor failure. Always run this test before replacing the sensor.
Perform the Stacker Capacity sensor test as follows:
1. In the Diagnostics menu, scroll to Stacker Capacity Sensor, select it, and press OK to start the test, or
Cancel to exit.
2. The sensor test starts, and the Front Panel prompts you to lift the first wheel holder containing the
capacity sensor.
Lift the wheel holder, and press OK to continue.
NOTE: Make sure that no object is interfering with the sensor.
174 Chapter 4 Diagnostics, Service Utilities and Calibrations ENWW
