6. To clean the drive roller and overdrive, see the user guide.
7. Once you have finished cleaning the Drive Roller and the Overdrive, press the Cancel key to stop the
roller.
Purge Tubes
NOTE: Make sure that NEW Ink Cartridges are installed or that the ink volume remaining in the Ink
cartridges is above 60cc before starting to fill the tubes. If you do not comply, you will get a warning message
and the printer will force you to replace the cartridges.
NOTE: Before using the Purge Tubes utility, you must make sure you have a new printhead.
Perform the Purge Tubes utility as follows:
1. In the Service Utilities submenu, scroll to Purge Tubes and select it.
2. The printer reboots.
3. After a time, a cartridge replacement screen appears.
4. Insert all cartridges and press OK.
5. If any of the cartridges have insufficient ink, the cartridge replacement will not allow you to leave until
they have all been purged. You have to replace cartridges that are not valid, and press OK again.
6. When the cartridge replacement process has successfully completed, a printhead replacement will be
opened.
7. The Front panel will prompt you to install a new printhead. Please follow the instructions.
8. The Front Panel prompts you to confirm that the printhead is replaced with a correctly inserted new
one. If it’s correctly inserted, press OK.
9. The product will now perform the Printhead Alignment and Front Panel will prompt you to continue with
the Printhead Alignment, select Align now and press the OK key.
10. Once the Printhead Alignment is completed, the following message will be displayed on the Front Panel.
Press the OK key to continue.
Reset Life Counters
The purpose of this Service Utility is to reset the internal life counters.
There are two submenus that allow you to:
●
Reset all the counters related to a Preventive Maintenance Kit (PMK).
●
Reset only the counters related to a specific replaced part.
NOTE: ALWAYS RESET THE LIFE COUNTER OF A CORRESPONDING PART AFTER REPLACING IT.
Perform the Reset Life Counters utility as follows:
1. In the Service Utilities submenu, scroll to Reset Life Counters and press this menu option.
2. Enter the 4-digit 2nd level access code “5494” and press OK.
182 Chapter 4 Diagnostics, Service Utilities and Calibrations ENWW
