226 Chapter 7 Parts and Diagrams
Parts and Diagrams
Electronics Module
Reference
on
Figure
HP Part
Number
Part Description Size
Page
a
a. Refers to the page in the Removal and Installation Chapter (if applicable)
1
Q6651-60306 Electronics Module Cables Kit All
N/A
2
Q1273-60237 EIO to PCI Interface Card All
360
3
Q6651-60268 OMAS Controller Card All
362
4
Q6651-60305
Sausalito PCI PCA
b
b. The 60-inch model can be used in a 42-inch printer but a 42-inch model CANNOT be
used in a 60-inch printer
42-inch
369
Q6652-60121
60-
inch
5
Q6651-60282
Main PCA Formatter (Includes Processor,
Heatsink & Fan).
All
375
6
Q6651-60348 Interconnect PCA All
357
7
Q6651-60313 Empty Electronics Module Assembly All
N/A
8
Q6651-60298 Electronics Module Metal Parts Kit All
N/A
9
Q1273-60251 Power Supply Unit (PSU) All
379
10
Q6651-60349 PrintMech PCA All
384
11
Q1273-60249
Memory Module SDRAM DIMM 32MX64
256M 184-DIM
All
373
12
Q6651-60352
Hard Disk Drive (Includes Holder and
screws)
All
377
13
Q6651-60282 CPU Fan All
-
Q6672 PCI USB PCA All
N/A
