232 Chapter 7 Parts and Diagrams
Parts and Diagrams
Right Hand Assemblies
Reference
on
Figure
HP Part
Number
Part Description Size
Page
a
a. Refers to the page in the Removal and Installation Chapter (if applicable)
1
Q1273-60086 Right Scan-Axis Bracket All
-
2
Q6651-60284
Service Station Assembly
b
b. Includes Service Station Cable
All
300
3
Q6651-60266 Primer Valves and Primer Tubes Assembly All
296
4
Q1273-60084 Aerosol Filter All
307
5
Q1273-60226 Aerosol Fan Assembly All
307
6
Q1273-60273
Service Station Cable (Includes
Maintenance Cartridge Door Sensor)
All
300
7
Q6651-60286 Vacuum Fan Assembly All
304
8
Q1273-60236 Drop Detector All
309
9
Q6651-60265 Primer Assembly All
294
10
Q6651-60273 Maintenance Cartridge All
-
To Next Page
