236 Chapter 7 Parts and Diagrams
Parts and Diagrams
Carriage Assembly
Reference
on
Figure
HP Part
Number
Part Description Size
Page
a
a. Refers to the page in the Removal and Installation Chapter (if applicable)
1
Q6651-60297
Line Sensor Assembly
b
b. Includes Line Sensor Holder and Cable
All
390
2
Q1273-60239
Encoder Sensorr (Includes Encoder Strip)
42-inch
331
Q6652-60119
60-
inch
3
Q6651-60290
Carriage Assembly
c
c. Does not include, Carriage PCA, Encoder Sensor, and Color Sensor
All
339
4
Q1273-60271 Cutter Assembly All
319
5
Q6651-60341
Carriage Stopper (includes Carriage
Stopper Screw and Media-Axis Motor
Bracket)
All
339
6
Q6651-60271 Color Sensor All
392
7
Q6651-60335 Setup Printhead Kit All
N/A
7
Q6651-60337 Carriage Flex Cables All
337
9
Q6651-60338 Carriage PCA All
334
