244 Chapter 7 Parts and Diagrams
Parts and Diagrams
Center Guide and Pinchwheel Assembly
Reference
on
Figure
HP Part
Number
Part Description Size
Page
a
a. Refers to the page in the Removal and Installation Chapter (if applicable)
1
Q6651-60280
Complete Pinchwheel Assembly
b
b. Includes Media Sensor
42-inch
425
Q6652-60110
60-
inch
2
Q6651-60345
Center Guide
42-inch
430
Q6652-60130
60-
inch
3
Q1273-60079 Media Sensor All
415
4
Q6651-60319 Media Lever Assembly All
420
5
Q1273-60082 Media Lever Sensor All
423
6
Q6651-60330 Pinchwheel Kit All
425
