248 Chapter 7 Parts and Diagrams
Parts and Diagrams
Take-Up Reel Assembly
Reference
on
Figure
HP Part
Number
Part Description Size
Page
a
a. Refers to the page in the Removal and Installation Chapter (if applicable)
1
Q6706-60902 Take-Up Reel Deflector Support Assembly All
445
2
Q6706-60904 Take-Up Reel Motor All
442
3
Q6706-60910 Thumbscrew All
447
4
Q6706-60909
Take-Up Reel Receiver Sensor Housing
Assembly
All
447
5
Q6706-60908 Take-Up Reel Sensors Assembly All
447
6
Q6706-60907
Take-Up Reel Spindle Assembly
b
b. Includes the Take-up Reel tubes. Not including the Take-Up Reel Spindle Hubs
42-inch
N/A
Q6652-60903
60-
inch
7
Q6706-60905
Take-Up Reel Deflector
42-inch
445
Q6652-60901
60-
inch
8
Q6706-60906
Take-Up Reel Tubes Assembly
42-inch
N/A
Q6652-60902
60-
inch
-
Q6706-60901 Take-Up Reel Spindle Hubs All
N/A
