250 Chapter 7 Parts and Diagrams
Parts and Diagrams
Miscellaneous Parts
Reference
on
Figure
HP Part
Number
Part Description Size
Page
a
a. Refers to the page in the Removal and Installation Chapter (if applicable)
b. This accessory is available to be purchased by the customer. In case of warranty replace-
ment you can use part number Q6651-60276
1
Q1273-60097 Right Arc All
439
2
Q1273-60098 Left Arc All
439
-
Q6715A
User’s Maintenance/cleaning kit
b
All
-
Q6651-60296 Preventive Maintenance Kit # 1:
• Scan-Axis Motor (see page 238)
• Encoder Strip (see page 238)
• Belt Assembly (see page 238)
• Carriage Assembly without PCA,
Cutter, and Color Sensor
42-inch
N/A
Q6652-60116
60-
inch
-
Q6651-60277
Preventive Maintenance Kit # 2:
• Aerosol Filter (see page 300)
• Service Station Aerosol Assembly
(see page 300)
• Ink Absorber (see User’s Guide)
• Left spittoon (see page 328)
• Color Sensor (see page 392)
• Line Sensor (see page 390)
• Encoder Strip (see page 238)
ALL
N/A
-
Q6651-60340 Labels Kit All
N/A
-
Q1273-60296
2 Sheets of HP Universal Instant.dry Gloss
Photo media for Service Advance
Calibration and OMAS Calibration
All
N/A
-
Power Cord (2.5 meters) for Australia All
N/A
-
Power Cord (2.5 meters) for most European
Countries, Korea, Indonesia, Portugal,
Germany, Spain, France, Italy and Arabia
All
N/A
-
Power Cord (2.5 meters) for Singapore,
Arabic Countries and United Kingdom
All
N/A
-
Power Cord (2.5 meters) for India, South
Africa
All
N/A
-
Power Cord (2.5 meters) for USA, Mexico,
Canada, Taiwan, Japan and Arabia.
All
N/A
-
Power Cord (2.5 meters) for Brazil, Thailand
and Philippines
All
N/A
-
Jumper Cord for Chile, Uruguay, Argentina All
N/A
-
Power Cord (2.3 meters) for Chili and
Uruguay (final cable that is connected to
5961-3590)
All
N/A
-
Power Cord (2.3 meters) for Argentina (final
cable that is connected to 5961-3590)
All
N/A
-
Power Cord (2.5 meters) for China All
N/A
To Next Page
