HP Designjet Z6100 Series - Page 11

12.
Take-up reel sensor
13.
Take-up reel spindle hub
Rear view 42–in and 60–in printers
HP Designjet Z6100 42–in Printer HP Designjet Z6100 60–in Printer
1.
Quick Reference Guide holder
2.
Hard power switch and power-cord plug in
3.
Sockets for communication cables and optional accessories
Take-up reel motor
NOTE: The take-up reel is a standard feature on the HP Designjet Z6100
60–in Printer. It is an optional accessory on the HP Designjet Z6100 42–in
Printer.
The printer's main components
3
Introduction
