HP Designjet Z6100 Series - Page 19

5.
Front panel
6.
Maintenance cartridge
7.
Paper-load lever
8.
Spindle
9.
Take-up reel deflector
10.
Take-up reel motor
11.
Take-up reel cable and sensor housing unit
12.
Take-up reel sensor
13.
Take-up reel spindle hub
Rear view 60–in printer
1.
Quick Reference Guide holder
2.
Hard power switch and power-cord plug in
3.
Sockets for communication cables and optional accessories
Take-up reel motor
NOTE: The take-up reel is a standard feature on the HP Designjet Z6100 60–in Printer. It is an
optional accessory on the HP Designjet Z6100 42–in Printer. See
Accessories on page 146.
