HP DL120

Component identification 13
• 2 DIMMs: 2A+4B
• 3 DIMMs: 2A+4B+1C
• 4 DIMMs: All DIMMs
SAS and SATA device numbering
• LFF device bay numbering
• SFF device bay numbering
SAS and SATA hard drive LEDs
Item Description
1
Fault/UID LED (amber/blue)
2
Online LED (green)
