SATA Channel 1 Master
SATA Channel 2 Master
For each, allows you to:
run HDD self-test for selected channel:
SMART Status Check
HDD Short Self-Test
HDD Extended Self-Test
set extended IDE drive on selected channel to:
None
Auto
set access mode on selected channel to:
Large
Auto
view:
Firmware Version
Capacity
Cylinder
Head
Precomp
Landing Zone
Sector
Floppy Controller Disables/enables the floppy disk controller.
Drive A Allows you to set Drive A to:
None
1.44M, 3.5 in.
Halt On Allows you to set POST error behavior to:
All Errors
No Errors
All but Keyboard
All but Diskette
All but Diskette/Keyboard
POST Delay Allows you to set a POST delay to:
0 seconds
5 seconds
10 seconds
Table 3 Computer Setup—Standard CMOS Features (continued)
ENWW Computer Setup (F10) Utilities 5

Other manuals for HP dx2200 - Microtower PC

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP dx2200 - Microtower PC and is the answer not in the manual?

HP dx2200 - Microtower PC Specifications

General IconGeneral
ChipsetIntel 945G Express
MemoryUp to 4 GB DDR2 SDRAM
GraphicsIntegrated Intel Graphics Media Accelerator 950
AudioIntegrated High Definition audio
NetworkIntegrated 10/100/1000 Ethernet
Front Ports2 USB 2.0, headphone, microphone
Power Supply300W
ProcessorIntel Pentium 4 or Intel Celeron
Optical DriveDVD-ROM
Expansion Slots1 PCI Express x16, 3 PCI
Operating SystemWindows XP Professional or FreeDOS
Rear Ports4 USB 2.0, VGA, Ethernet, Line-in, Line-out, Microphone
StorageSATA Hard Drive (capacity varies)
USB Ports8 USB 2.0 (2 front, 4 rear, 2 internal)
