Integrated Intel 82566DM
Gigabit Network
Connection
Connector
RJ-45
Controller
Intel Nineveh Gigabit platform LAN Connect Networking Controller
Memory
Integrated 96KbB on chip buffer memory
Data rates supported
10/100/1000 Mbps
Compliance
IEEE 802.1P, 802.1Q, 802.2, 802.3, 802.3 ab and 802.3u compliant,
Bus architecture
GLCI, LCI interface. Intel specific MAC to PHY interface
Data transfer mode
At gigabit GLCI (802.3 serdes) is for Data, LCI (parallel bus)for MDIO, at 10/100
LCI for both data and MDIO, GLCI is idle.
Hardware certifications
FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for
European Union
Power requirement
Require 3.3Vaux,1.8V and 1.0V or just 3.3V with integrated regulators
Power consumption 1.16 Watts for 82566, whole LOM 2.53 Watts
ACBS
Intel Auto Connect Battery Saving feature
Boot ROM support
Yes
Network transfer mode
Full-duplex
Half-duplex (not available for the 1000BASE-T transceiver)
Network transfer rate
10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps
Environmental
Operating temperature
32° to 131°F (0° to 55° C)
To 70° C for external regulator
Operating humidity
85% at 131° F (55° C)
Management capabilities
WOL, auto MDI crossover, PXE, Muti-port teaming, RSS, Advanced cable
diagnostic.
Alerting
ASF 2.0 support
QuickSpecs
HP Compaq dx7300 Business PC
Technical Specifications - Communications
DA - 12583 Worldwide — Version 15 — September 19, 2007
Page 22
