Eco-Label Certifications
and declarations
This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
US Federal Energy Management Program (FEMP)
Taiwan Green Mark
China Energy Conservation Program
IT ECO declaration
Korea Eco-label
EPEAT Rated – SILVER
Japan PC Green label*
*
This product conforms to the examination standards (2003 version) under JEITA's 'PC Green Label
System.'
Slim Tower
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the Slim Tower
Desktop model is based on a typically configured product
Energy Consumption
115 VAC 230 VAC 100 VAC
Normal Operation
99.0 W 94.0 W 99.5 W
Sleep (low power
mode)
2.64 W 2.87 W 2.62 W
Off
1.68 W 1.87 W 1.67 W
Heat Dissipation*
115 VAC 230 VAC 100 VAC
Normal Operation
337.8 BTU/hr 320.7 BTU/hr 339.5 BTU/hr
Sleep
9.0 BTU/hr 9.8 BTU/hr 8.9 BTU/hr
Off
5.7 BTU/hr 6.4 BTU/hr 5.7 BTU/hr
*
Heat dissipation is calculated based on the measured watts, assuming the service level is attained for
one hour.
This product is in compliance with US executive order 13221, WOL (wake on LAN) disabled.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
System Fan Off
Sound Power
(LWAd, bels)
Sound Pressure
(LpAm, decibels)
Idle
TBD TBD
Fixed Disk (random
writes)
TBD TBD
Optical Drive
(sequential reads)
TBD TBD
QuickSpecs
HP Compaq dx7300 Business PC
Technical Specifications - Environmental Data
DA - 12583 Worldwide — Version 15 — September 19, 2007
Page 48
