HP Elite x2 1011 G1 Quickspecs

QuickSpecs
HP Elite x2 1011 G1
Technical Specifications
Not all configuration components are available in all regions/countries.
c04507222 – DA – 15130 — Worldwide - Version 9 –January 20, 2016
Page 31
Integrated Microphone
Yes, dual digital microphone array
Audio Output Quality
Frequency Response
20 Hz - 20 kHz
Signal to Noise Ratio
>85 dB
Total Harmonic
Distortion
0.01%
Noise Floor
-110 dB
Play/Record Sampling
Rate(s)
8 kHz - 48kHz
DAC
16, 20 or 24-bit
ADC
16 or 20-bit
Internal Stereo Speaker
Power Rating
1.5Watt
Impedance
8 ohms
POWER
HP 45W Smart AC Adapter
non-slim
Dimensions (H x W x D)
95.0 x 40.0 x 26.5mm
Input
90 to 265 VAC
Input Efficiency
88% min at 115 VAC / 89% min at 230VAC
Input frequency range
47 to 63 Hz
Input AC current
1.4 A at 90 VAC and maximum load
Output
Output power
45W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<8A, Over voltage protection- 29V max
automatic shutdown
Connector
3 pin/non-grounded, mates with 4.5mm barrel type Smart ID DC connector
Environmental Design
Operating
temperature
32° to 95° F (0° to 35° C)
Non-operating (storage)
temperature
-4° to 121° F (-20° to 85° C)
Altitude
0 to 16,405 ft (0 to 5,000 m)
Humidity
0% to 95%
Storage Humidity
0% to 95%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals
- C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; Reliability - failure rate of less than 0.1% annually within
the first three years of operation.
HP 45W Smart AC Adapter
non-slim 2 prong
Dimensions (H x W x D)
95.0 x 40.0 x 26.5mm
Input
90 to 265 VAC
Input Efficiency
88% min at 115 VAC / 89% min at 230VAC
Input frequency range
47 to 63 Hz
Input AC current
1.4 A at 90 VAC and maximum load
Output
Output power
45W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input

HP Elite x2 1011 G1 Specifications

General

Stepping	F0
Tjunction	95 °C
Processor code	SR23L
Processor cache	4 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel® Core™ M
Processor series	Intel Core M-5Y Mobile series
Processor threads	4
Processor codename	Broadwell
Processor frequency	1.1 GHz
Processor cache type	L3
Processor manufacturer	Intel
Processor package size	30 x 16.5 mm
Conflict-Free processor	Yes
Processor front side bus	- MHz
Processor boost frequency	2.6 GHz
Processor operating modes	32-bit, 64-bit
Graphics & IMC lithography	14 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	4.5 W
Scenario Design Power (SDP)	3.5 W
Configurable TDP-down frequency	0.6 GHz
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3L-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	256 GB
Display diagonal	11.6 \
Touch technology	Multi-touch
Graphics card	HD Graphics 5300
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Processor ARK ID	84669
Processor socket	BGA 1234
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Near Field Communication (NFC)	-
Microphone in	No
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Country of origin	China
Device type	Tablet PC
Form factor	Slate
Product color	Black, Silver
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Battery capacity	- mAh
Battery life (max)	9 h
Platform	Windows
Operating system installed	Windows 8.1 Pro

Weight and Dimensions

Depth	192.7 mm
Width	298 mm
Height	10.7 mm
Weight	780 g
