To start Refresh:
1. On the Start screen, point to the far-right upper or lower corner of the screen to display
the charms.
2.
Click Settings.
3.
Click Change PC settings in the bottom-right corner of the screen, and then select General
from the PC settings screen.
4. Under Refresh your PC without affecting your files, select Get started, and follow the
on-screen instructions.
Remove everything and reinstall Windows
Sometimes you want to perform detailed reformatting of your computer, or you want to remove
personal information before you give away or recycle your computer. The process described in this
section provides a speedy, simple way to return the computer to its original state. This option removes
all personal data, apps, and settings from your computer, and reinstalls Windows.
IMPORTANT: This option does not provide backups of your information. Before using this option,
back up any personal information you wish to retain.
You can initiate this option by using the f11 key or from the Start screen.
To use the f11 key:
1. Press f11 while the computer boots.
– or –
Press and hold f11 as you press the power button.
2. Select Troubleshoot from the boot options menu.
3. Select Reset your PC, and follow the on-screen instructions.
To use the Start screen:
1. On the Start screen, point to the far-right upper or lower corner of the screen to display
the charms.
2. Click Settings.
3. Click Change PC settings in the bottom-right corner of the screen, and then select General
from the PC settings screen.
4. Under Remove everything and reinstall Windows, select Get started, and follow the
on-screen instructions.
Windows 8
125

Table of Contents

Other manuals for HP EliteBook 2570p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 2570p and is the answer not in the manual?

HP EliteBook 2570p Specifications

General IconGeneral
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Memory form factorSO-DIMM
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
LED backlightYes
Display diagonal12.5 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Bus typeDMI
SteppingL1
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modeli5-3210M
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-3200 Mobile series
Processor socketBGA 1023
Processor threads4
Processor codenameIvy Bridge
Processor frequency2.5 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.1 GHz
Processor operating modes64-bit
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)25
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® QM77 Express
HDD speed7200 RPM
HDD interfaceSATA II
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Total storage capacity500 GB
Compatible memory cardsSD
Number of HDDs installed1
On-board graphics card ID0x166
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1100 MHz
Intel segment taggingEnterprise
Audio systemSRS Pro
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Cabling technology10/100/1000Base-T(X)
Top Wi-Fi standardWi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity0
Keyboard layout-
Pointing deviceTouchpad
Operating system installedWindows 8 Pro
Form factorClamshell
Product typeLaptop
Product colorGray
Country of originChina
Battery capacity55 Wh
Battery life (max)- h
Number of battery cells6
AC adapter power65 W
Sustainability certificatesENERGY STAR
Processor codeSR0N0
Processor ARK ID65708
Processor package size31.0 x 24.0 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth209 mm
Width305 mm
Height27 mm
Weight1630 g
