Page #139 background imageLoading...
Page #139 background image
SuSE Linux (SLED)
Recovery after a system failure is as good as your most recent backup. As you add new software and
data files, you should continue to back up your system on a regular basis to maintain a reasonably
current backup.
Your computer includes tools provided by HP to help you safeguard your information and retrieve it if
ever needed.
Creating backups
1. Create restore media immediately after you set up the computer. For more information, see the
“Performing a system recovery” section.
2. As you add files, routinely create a backup of your system and personal information.
Backing up your information
You should back up your computer files on a regular schedule to maintain a current backup. You can
manually back up your information to an optional external drive, a network drive, or discs. Back up
your system at the following times:
At regularly scheduled times
Before the computer is repaired or restored
Before you add or modify hardware or software
To back up your home directory files using Backup Manager Settings:
1. Select Computer > More Applications > Tools > Backup Manager Settings, and click
Backup my home directory.
2. Click Storage Destination Location, and then select a location to back up your information.
3. Click Schedule, and then select a time schedule to perform backups at a regularly scheduled
time.
To immediately back up your information, click the Backup Now check box.
NOTE: Before you back up your information, be sure you have designated a location to save
the backup files.
4. Click Save and Backup to start the backup and to save the backup settings.
To restore backup files:
1. Select Computer > More Applications > Tools > Backup Manager Restore.
2. Click Backup Source, and then select the location of the backup files.
3. Click Restore Destination, and then select the destination to restore the files.
SuSE Linux (SLED)
131

Table of Contents

Other manuals for HP EliteBook 2570p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 2570p and is the answer not in the manual?

HP EliteBook 2570p Specifications

General IconGeneral
Memory slots2x SO-DIMM
Internal memory4 GB
Memory clock speed1600 MHz
Memory form factorSO-DIMM
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
LED backlightYes
Display diagonal12.5 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
Bus typeDMI
SteppingL1
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modeli5-3210M
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-3200 Mobile series
Processor socketBGA 1023
Processor threads4
Processor codenameIvy Bridge
Processor frequency2.5 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.1 GHz
Processor operating modes64-bit
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)25
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® QM77 Express
HDD speed7200 RPM
HDD interfaceSATA II
Storage mediaHDD
Optical drive typeDVD Super Multi DL
Total storage capacity500 GB
Compatible memory cardsSD
Number of HDDs installed1
On-board graphics card ID0x166
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1100 MHz
Intel segment taggingEnterprise
Audio systemSRS Pro
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Cabling technology10/100/1000Base-T(X)
Top Wi-Fi standardWi-Fi 4 (802.11n)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity0
Keyboard layout-
Pointing deviceTouchpad
Operating system installedWindows 8 Pro
Form factorClamshell
Product typeLaptop
Product colorGray
Country of originChina
Battery capacity55 Wh
Battery life (max)- h
Number of battery cells6
AC adapter power65 W
Sustainability certificatesENERGY STAR
Processor codeSR0N0
Processor ARK ID65708
Processor package size31.0 x 24.0 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth209 mm
Width305 mm
Height27 mm
Weight1630 g
