3.
Disconnect the RJ-11 cable (3) from the modem module.
4. Remove the modem module.
Reverse this procedure to install the modem module.
Keyboard
NOTE: The keyboard spare part kit includes a pointing stick, keyboard cable, and pointing stick
cable.
For use in country/region Spare part
number
For use in country/region Spare part
number
For use only on computer models equipped with the Windows
8 Standard and Professional operating system:
For use in the Netherlands 701979-B31
For use in Belgium 701979-A41 For use in Norway 701979-091
For use in Brazil 701979-201 For use in Northwest Africa 701979-FP1
For use in Bulgaria 701979-261 For use in Portugal 701979-131
For use in Canada 701979-DB1 For use in Romania 701979-271
For use in the Czech Republic and
Slovakia
701979-FL1 For use in Russia 701979-251
For use in Denmark 701979-081 For use in Saudi Arabia 701979-171
For use in France 701979-051 For use in Slovenia 701979-BA1
For use in Germany 701979-041 For use in South Korea 701979-AD1
For use in Greece 701979-151 For use in Spain 701979-071
For use in Hungary 701979-211 For use in Sweden and Finland 701979-B71
For use in Iceland 701979-DD1 For use in Switzerland 701979-BG1
For use in India 701979-D61 For use in Taiwan 701979-AB1
Component replacement procedures
69

HP EliteBook 2570p Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
LED backlight	Yes
Display diagonal	12.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3210M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
HDD speed	7200 RPM
HDD interface	SATA II
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Intel segment tagging	Enterprise
Audio system	SRS Pro
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Keyboard layout	-
Pointing device	Touchpad
Operating system installed	Windows 8 Pro
Form factor	Clamshell
Product type	Laptop
Product color	Gray
Country of origin	China
Battery capacity	55 Wh
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR
Processor code	SR0N0
Processor ARK ID	65708
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	209 mm
Width	305 mm
Height	27 mm
Weight	1630 g
