Page #119 background imageLoading...
Page #119 background image
11 Security
Protecting the computer
NOTE: Security solutions are designed to act as deterrents. These deterrents may not prevent a
product from being mishandled or stolen.
NOTE: Your computer supports CompuTrace, which is an online security-based tracking and
recovery service available in select regions. If the computer is stolen, CompuTrace can track the
computer if the unauthorized user accesses the Internet. You must purchase the software and
subscribe to the service in order to use CompuTrace. For information about ordering the CompuTrace
software, go to the HP Web site at
http://www.hpshopping.com.
Security features provided with your computer can protect the computer, personal information, and
data from a variety of risks. The way you use your computer will determine which security features
you need to use.
The Windows operating system offers certain security features. Additional security features are listed
in the following table. Most of these additional security features can be configured in the Computer
Setup utility (referred to hereafter as Computer Setup).
To protect against Use this security feature
Unauthorized use of the computer HP ProtectTools Security Manager, in combination with a
password, smart card, and/or fingerprint reader
Unauthorized access to Computer Setup (f10) BIOS administrator password in Computer Setup*
Unauthorized access to the contents of a hard drive DriveLock password in Computer Setup*
Unauthorized startup from an optical drive, diskette drive, or
internal network adapter
Boot options feature in Computer Setup*
Unauthorized access to a Windows user account HP ProtectTools Security Manager
Unauthorized access to data
Firewall software
Windows updates
Drive encryption for HP ProtectTools
Unauthorized access to Computer Setup settings and other
system identification information
BIOS administrator password in Computer Setup*
Unauthorized removal of the computer Security cable slot (used with an optional security cable)
*Computer Setup is a preinstalled, ROM-based utility that can be used even when the operating system is not working or will
not load. You can use either a pointing device (TouchPad, pointing stick, or USB mouse) or the keyboard to navigate and
make selections in Computer Setup.
Protecting the computer 107
Downloaded from LpManual.com Manuals

Table of Contents

Other manuals for HP EliteBook 2740p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 2740p and is the answer not in the manual?

HP EliteBook 2740p Specifications

General IconGeneral
Bus typeDMI
SteppingC2
Tjunction105 °C
Processor cache3 MB
Processor cores2
System bus rate2.5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-500 Mobile Series
Processor socketBGA 956
Processor threads4
Processor codenameArrandale
Processing Die size81 mm²
Processor frequency2.53 GHz
Processor cache typeSmart Cache
Processor technologyIntel Centrino 2 w/ vPro
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.07 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)19
Maximum number of PCI Express lanes16
Number of Processing Die Transistors382 M
Display-
Modem speed56 Kbit/s
Battery typeHP Long Life 6-cell (39 WHr) Lithium-Ion Primary Battery
Graphics cardHD Graphics
Internal modemYes
Expansion slots1 Express Card/34; 1 Smart Card Reader; 1 secure digital/MultiMedia card
Video card noteMicrosoft DirectX 10 (Shader 4.0) and OpenGL 2.1 capable, with DDR3 system memory
Dimensions (WxDxH)290 x 212 x 31.7 mm
Power requirementsExternal 65W Smart AC adapter; Power cord (1.8 meters, with AC adapter 3.66 meters); HP Fast Charge
HDD controller typeSolid State Drive SATA II (5400 rpm)
Wireless technologyIntel 802.11a/b/g; HP Integrated Module with Bluetooth 2.1 Wireless Technology
Maximum HDD capacity320 GB
Intel segment taggingEnterprise
Minimum storage drive space160 GB
Compatible operating systemsGenuine Windows Vista Enterprise 32; Genuine Windows Vista Enterprise 64; Genuine Windows 7 Home Premium; SuSE Linux Enterprise 10
Main camera resolution (numeric)2 MP
Bluetooth version2.1+EDR
Networking featuresIntegrated Intel 82577 Gigabit Ethernet (10/100/1000 NIC)
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Memory slots2x SO-DIMM
Memory upgrade8 GB
Internal memory4 GB
Memory clock speed1333 MHz
HDD capacity0 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
Display diagonal12.1 \
Display resolution1280 x 800 pixels
Native aspect ratio16:10
Audio systemHD
Audio includedHigh Definition Audio support with 24-bit DAC, Integrated stereo speakers, Integrated dual-microphone array, Touch-sensitive controls for volume up, volume down, and mute, Combo headphone/mic jack
Motherboard chipsetIntel® QM57 Express
I/O ports3 USB 2.0; 1 1394a; 1 AC power; 1 combo stereo headphone/mic jack; 1 docking connector; 1 RJ-11; 1 RJ-45; 1 secondary battery connector; 1 VGA-in
Charging port typeDC-in jack
USB 2.0 ports quantity3
Firewire (IEEE 1394) ports1
Number of battery cells6
Trial softwareWinZip 12; Microsoft Office Professional 2007; HP SkyRoom
Bundled softwareHP Recovery Manager; HP Support Assistant; HP QuickLaunch Buttons; HP QuickLook 3; HP QuickWeb; HP DayStarter; HP Power Assistant; HP Connection Manager; HP Wireless Assistant
Operating system installedWindows 7 Professional
Form factorConvertible (Swivel)
Product typeHybrid (2-in-1)
Country of originChina
Storage drive type160 GB Solid State Drive SATA II Hard Drive 160, 250 or 320 GB (5400 rpm), Solid State Drive 80 or 160 GB, HP 3D DriveGuard
Keyboard typeHP spill-resistant keyboard, HP Night Light shines directly on the keyboard for low-light conditions
Keyboard layoutQWERTY
Processor ARK ID43544
Processor package sizerPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography45 nm
Supported instruction setsSSE4.1/4.2
Intel® Turbo Boost Technology1.0
Physical Address Extension (PAE)36 bit
On-board graphics card modelIntel® HD Graphics
On-board graphics card base frequency500 MHz
On-board graphics card dynamic frequency (max)766 MHz
Weight and Dimensions IconWeight and Dimensions
Depth212 mm
Width290 mm
Height31.7 mm
Weight1720 g
