Page #44 background imageLoading...
Page #44 background image
Cannot connect to a preferred network
Windows can automatically repair a corrupted WLAN connection:
If there is a network icon in the notification area, at the far right of the taskbar, right-click the
icon, and then click Troubleshoot problems.
Windows resets your network device and attempts to reconnect to one of the preferred
networks.
If there is no network icon in the notification area, follow these steps:
1. Select Start > Control Panel > Network and Internet > Network and Sharing Center.
2. Click Troubleshoot problems and select the network you wish to repair.
Network icon is not displayed
If the network icon is not displayed in the notification area after you configure the WLAN, the software
driver is either missing or corrupted. A Windows “Device not Found” error message may also be
displayed. The driver must be reinstalled.
To get the latest version of the WLAN device software for your computer, follow these steps:
1. Open your Internet browser and go to
http://www.hp.com/support.
2. Select your country or region.
3. Click the option for software and driver downloads, and then type your computer model number
in the search box.
4. Press enter, and then follow the on-screen instructions.
NOTE: If the WLAN device you are using was purchased separately, consult the manufacturer's
Web site for the latest software.
Current network security codes are unavailable
If you are prompted for a network key or a name (SSID) when connecting to a WLAN, the network is
protected by security. You must have the current codes to make a connection on a secure network.
The SSID and network key are alphanumeric codes that you enter into your computer to identify your
computer to the network.
For a network connected to your personal wireless router, review the router user guide for
instructions on setting up the same codes on both the router and the WLAN device.
For a private network, such as a network in an office or at a public Internet chat room, contact
the network administrator to obtain the codes, and then enter the codes when prompted to do
so.
Some networks change the SSID or network keys used in their routers or access points on a
regular basis to improve security. You must change the corresponding code in your computer
accordingly.
32 Chapter 3 Networking
Downloaded from LpManual.com Manuals

Table of Contents

Other manuals for HP EliteBook 2740p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 2740p and is the answer not in the manual?

HP EliteBook 2740p Specifications

General IconGeneral
Bus typeDMI
SteppingC2
Tjunction105 °C
Processor cache3 MB
Processor cores2
System bus rate2.5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-500 Mobile Series
Processor socketBGA 956
Processor threads4
Processor codenameArrandale
Processing Die size81 mm²
Processor frequency2.53 GHz
Processor cache typeSmart Cache
Processor technologyIntel Centrino 2 w/ vPro
Processor lithography32 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.07 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)19
Maximum number of PCI Express lanes16
Number of Processing Die Transistors382 M
Display-
Modem speed56 Kbit/s
Battery typeHP Long Life 6-cell (39 WHr) Lithium-Ion Primary Battery
Graphics cardHD Graphics
Internal modemYes
Expansion slots1 Express Card/34; 1 Smart Card Reader; 1 secure digital/MultiMedia card
Video card noteMicrosoft DirectX 10 (Shader 4.0) and OpenGL 2.1 capable, with DDR3 system memory
Dimensions (WxDxH)290 x 212 x 31.7 mm
Power requirementsExternal 65W Smart AC adapter; Power cord (1.8 meters, with AC adapter 3.66 meters); HP Fast Charge
HDD controller typeSolid State Drive SATA II (5400 rpm)
Wireless technologyIntel 802.11a/b/g; HP Integrated Module with Bluetooth 2.1 Wireless Technology
Maximum HDD capacity320 GB
Intel segment taggingEnterprise
Minimum storage drive space160 GB
Compatible operating systemsGenuine Windows Vista Enterprise 32; Genuine Windows Vista Enterprise 64; Genuine Windows 7 Home Premium; SuSE Linux Enterprise 10
Main camera resolution (numeric)2 MP
Bluetooth version2.1+EDR
Networking featuresIntegrated Intel 82577 Gigabit Ethernet (10/100/1000 NIC)
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)10 - 90 %
Memory slots2x SO-DIMM
Memory upgrade8 GB
Internal memory4 GB
Memory clock speed1333 MHz
HDD capacity0 GB
SSD capacityThe Solid State Drive's storage capacity in Gigabytes.
Display diagonal12.1 \
Display resolution1280 x 800 pixels
Native aspect ratio16:10
Audio systemHD
Audio includedHigh Definition Audio support with 24-bit DAC, Integrated stereo speakers, Integrated dual-microphone array, Touch-sensitive controls for volume up, volume down, and mute, Combo headphone/mic jack
Motherboard chipsetIntel® QM57 Express
I/O ports3 USB 2.0; 1 1394a; 1 AC power; 1 combo stereo headphone/mic jack; 1 docking connector; 1 RJ-11; 1 RJ-45; 1 secondary battery connector; 1 VGA-in
Charging port typeDC-in jack
USB 2.0 ports quantity3
Firewire (IEEE 1394) ports1
Number of battery cells6
Trial softwareWinZip 12; Microsoft Office Professional 2007; HP SkyRoom
Bundled softwareHP Recovery Manager; HP Support Assistant; HP QuickLaunch Buttons; HP QuickLook 3; HP QuickWeb; HP DayStarter; HP Power Assistant; HP Connection Manager; HP Wireless Assistant
Operating system installedWindows 7 Professional
Form factorConvertible (Swivel)
Product typeHybrid (2-in-1)
Country of originChina
Storage drive type160 GB Solid State Drive SATA II Hard Drive 160, 250 or 320 GB (5400 rpm), Solid State Drive 80 or 160 GB, HP 3D DriveGuard
Keyboard typeHP spill-resistant keyboard, HP Night Light shines directly on the keyboard for low-light conditions
Keyboard layoutQWERTY
Processor ARK ID43544
Processor package sizerPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography45 nm
Supported instruction setsSSE4.1/4.2
Intel® Turbo Boost Technology1.0
Physical Address Extension (PAE)36 bit
On-board graphics card modelIntel® HD Graphics
On-board graphics card base frequency500 MHz
On-board graphics card dynamic frequency (max)766 MHz
Weight and Dimensions IconWeight and Dimensions
Depth212 mm
Width290 mm
Height31.7 mm
Weight1720 g
