HP EliteBook 745 G5 - Memory and Storage Configurations; Connectivity and Networking

Category Description
DDR4-2400 dual channel support
Supports up to 32 GB of system RAM in the following congurations:
●
32768 MB (16384 MB×2)
●
24576 MB (16384 MB×1 + 8192 MB×1)
●
20480 MB (16384 MB×1 + 4096 MB×1)
●
16384 MB (16384 MB×1 or 8192 MB×2)
●
12288 MB (8192 MB×1 + 4096 MB×1)
●
8192 MB (8192 MB×1 or 4096 MB×2)
●
4096 MB (4096 MB×1)
Primary storage M.2 solid-state drives (2280):
512 GB, PCIe, Gen3×4, SS, NVMe, TLC, Opal 2
512 GB, PCIe, Gen3×4, SS, NVMe, TLC
512 GB, SATA-3, SS, TLC, FIPS-140-2
360 GB, PCIe, Gen3×4, NVMe, SS, TLC
256 GB, PCIe, Gen3×4, NVMe, SS, TLC
256 GB, PCIe, NVMe, SS, value
256 GB, SATA-3, Opal 2, TLC
128 GB, SATA-3, SS, TLC
Audio and video HP Bang & Olufsen Audio
Multi-array microphone (including World-Facing 3rd microphone)
Stereo speakers (2) (13 mm × 38 mm × 4 mm)
Camera HD RGB 720p (select models only)
Camera HD+IR RGB 720p (select models only)
Camera privacy shutter (only with non-touch camera panels)
Supports WDR (Wide Dynamic Range)
Ethernet Realtek PCIe GbE Family Controller 10/100/1000 with DASH Support
RTL8111EPH-CG
The following support S3/S4/S5 wake on LAN: embedded NIC.
*The following support S3/S4/S5 wake on LAN/HBMA (via out of band): HP Elite USB-C Dock G3, HP USB-C Dock
G4, HP USB-C Universal Dock, HP Thunderbolt Dock 120W, and HP USB-C Mini Dock.
Wireless
networking
WPAN Bluetooth:
Integrated wireless personal area network (PAN) supported by Bluetooth
®
4.2 combo card
Wireless local area network (WLAN) (select models only):
Integrated WLAN options with dual antennas (M.2 2230 socket PCIe/USB)
Supports the following WLAN formats:
2 Chapter 1 Product description
