HP EliteBook 8460p User Manual

Service Desk Knowledge Management – US Service Desk Knowledge Mgt (US – Hermitage)
How to adjust the volume
Increase: Press Fn + F7.
Decrease: Press Fn + F6.
Mute: Press the Mute button above the Delete key.
How to connect to a projector
1. Plug the video cable into the external monitor port
(VGA) on the back of the laptop.
2. Press Fn+F4 and select the option to enable both
the laptop LCD and external monitor/projector.
3. Use Windows Display Settings to adjust the
resolution to the desired setting.
How to turn on/off the Wireless card
Press the Wireless button above the Backspace key to
toggle the wireless card on/off.
Function key functions
Fn + F3: Sleep
Fn + F4: Display toggle
Fn + F6: Volume down
Fn + F7: Volume up
Fn + F8: Battery settings
Fn + F9: Decrease LCD brightness
Fn + F10: Increase LCD brightness
Fn + F11: Ambient light sensor
Fn + Scroll: Number Lock (Num Lk)
Fn + Pause Break
Fn + Insert: Print Screen (Prt Sc)
How to adjust the brightness
Increase: Press Fn+F10.
Decrease: Press Fn+F9.
Turn on/off Ambient light sensor: Automatically adjusts
brightness based on the brightness of the surroundings.
Press Fn+F11 to toggle on/off.
Notification LEDs
(from left to right)
Wireless light
• White: Integrated wireless device on
• Amber: Wireless devices off
Power light
• On: Computer on
• Blinking: Sleep/Standby mode
• Off: Computer off or hibernating
Battery light
• Amber: Battery charging
• White: Battery close to full charge capacity
• Amber (Blinking): Battery low
• Off: Computer using battery for power or power
cord is plugged in, the battery is fully charged
Drive light
• Blue: Accessing hard drive or optical drive
• Amber: Hard drive temporarily parked
• Off: No disk activity
Touchpad on/off light
• Off: Touchpad is enabled
• Amber: Touchpad is disabled
Laptop details
Disclaimer: The manufacturer may change hardware
specification during production. These changes may cause
slight variations in hard drive size, processor speed, etc.
Model
HP EliteBook 8460p
Description
Full size HP Wide Screen Laptop
Processor
Intel Core i5-2520M (2.50GHz)
Memory (RAM)
• Windows (64-bit): 8 GB
• Windows (32-bit): 4 GB
(32-bit platform is only able to
utilize maximum of 3 GB RAM)
Hard Drive
256GB Solid State Drive
Optical Media
DVD RW LightScribe Optical Drive
Display
14.1 HD+ LED Display (1600 x 900)
Graphics
Integrated Intel HD Graphics 3000
Webcam
Integrated 720p webcam
PC Card Slots
• ExpressCard 54
• SmartCard reader
• SD/ MMC
Wireless
Intel 6300 802.11a/b/g/n
I/O Ports and
Connectors
• 2 USB 3.0
• 1 USB 2.0-Powered (allows USB
devices to be powered/charged
when the laptop is turned off)
• 1 eSATA/USB 2.0 combo port
• VGA External Monitor port
• Display Port
• RJ-11
• RJ-45
• Headphone
• Microphone
• 1394a Firewire
• AC power connector
• Docking connector
• Secondary battery connector
Keyboard
Standard
Pointing Device
Trackpoint and Touchpad
Privacy Filter
Optional
Bluetooth
Bluetooth 2.1+
Dimensions
1.25"H x 13.31"W x 9.11"D
Weight
4.68 lbs.

HP EliteBook 8460p Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-2410M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-2400 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	23
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD-RW
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Power supply type	AC/DC
Intel segment tagging	Enterprise
Operating temperature (T-T)	41 - 95 °F
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Audio system	SRS Premium Sound
Pointing device	Touchpad
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	3
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
AC adapter power	65 W
Battery capacity	62 Wh
Number of battery cells	6
Storage relative humidity (H-H)	10 - 90 %
Sustainability certificates	ENERGY STAR
Product color	Black, Silver
Country of origin	China
On-board graphics card ID	0x116
Discrete graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Processor ARK ID	52224
Processor package size	37.5x37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	231 mm
Width	338 mm
Height	34 mm
Weight	2070 g
