HP EliteBook 8470w Specifications

EliteBook 8470w Mobile Workstation
Form Factor
Operating system
Preinstalled:
Genuine® Windows 7 Professional 32
8
Genuine Windows 7 Professional 64
8,9
Genuine Windows 7 Home Premium 64
8,9
FreeDOS
Supported:
Genuine Windows 7 Enterprise
8
Genuine Windows 7 Ultimate
8
Genuine Windows XP Professional
SUSE Linux Enterprise Desktop 11 SP2
Red Hat Enterprise Linux 6.x
Certied:
SUSE Linux Enterprise Desktop 11 SP2
Red Hat Enterprise Linux 6.x
Processor
3rd Generation Intel® Core™ i7
10
with Turbo Boost Technology;
11
3rd Generation Intel® Core™ i5
10
with Turbo Boost Technology
11
Chipset
Mobile Intel® QM77 Express (vPro™ support
12
)
Memory
DDR3 SDRAM, 1600 MHz, two slots supporting dual-channel memory, 2/4/8 GB SODIMMs, up to 16 GB total
13
Internal Storage
14
320/500/750 GB 7200 rpm SMART SATA II HDD, 500 GB 7200 rpm SED (Self Encrypting Drive) HDD, 128/180 GB SATA 6 GB/s SSD, or 256 GB SATA 6 GB/s
SED SSD, HP 3D DriveGuard
15
Flash Cache
Optional 24 GB mSATA Flash cache module;
7,16
Support Intel Smart Response Technology
Upgrade Bay
12.7 mm SATA optical drive or secondary hard drive: Blu-ray R/RE DVD+/-RW SuperMulti DL Drive,
7,17
Blu-ray ROM DVD+/-RW SuperMulti DL Drive,
7,17
DVD+/–RW SuperMulti DL Drive,
7,17
DVD-ROM Drive,
7
500 GB 7200 rpm secondary HDD;
7,14
or weight saver
Display
14.0" diagonal LED-backlit HD
3
anti-glare (1366 x 768), 14.0" diagonal LED-backlit HD+
3
anti-glare (1600 x 900)
Graphics
AMD FirePro
TM
M2000 with 1 GB dedicated GDDR5 video memory; AMD Eyenity Technology for advanced multi-monitor support
1
Audio/Visual
High Denition Audio (SRS Premium Sound Pro), stereo speakers, stereo headphone/line out, stereo microphone in, optional HD
3
Webcam,
7
integrated
dual-microphone array
Wireless Support
7,18,19
Optional HP hs2350 HSPA+ Mobile Broadband;
7,18
Optional HP un2430 EV-DO/HSPA Mobile Broadband;
7,18
Intel® Centrino 802.11a/b/g/n 3x3;
19
Intel®
Centrino 802.11a/b/g/n 2x2;
19
Broadcom 802.11a/b/g/n 2x2;
19
HP Integrated Module with Bluetooth® v4.0; HP Connection Manager
Communications
Integrated Intel® 82579LM Gigabit Network Connection (vPro™ support
11
); 56K v.92 modem
7
Ports and Connectors
2 USB 3.0 ports, 1 USB 2.0 charging port, eSATA/USB 2.0 combo, VGA, DisplayPort, stereo microphone in, stereo headphone/line out, 1394a, power
connector, RJ-11(optional modem), RJ-45(Ethernet), docking connector, secondary battery connector
Expansion Slots
1 ExpressCard/54, 1 SD/MMC slot
Input Devices
Full-sized spill-resistant keyboard with bottom case drain, touchpad with scroll and gestures support, point stick, launch buttons (Web browser, WLAN
on/o, mute)
Software (Windows OS only)
HP Power Assistant,
20
HP Recovery Manager, HP Support Assistant, Corel WinDVD (select model), Roxio Secure Burn
21
(select models), Roxio MyDVD
Business 2010 (select models), Adobe® Flash Player, PDF Complete Corporate Edition, WinZip Basic, HP Performance Advisor, HP GPS and Location
22
(select models), Microsoft® Oce Starter: reduced-functionality Word and Excel® only, with advertising. No PowerPoint® or Outlook®. Buy Oce 2010
to use the full-featured software.
23
Custom Integration Services provides tailor-made, turnkey solutions for Business Ready PCs.
Security
Standard: Microsoft Security Essentials, HP ProtectTools,
15
Central Management for HP ProtectTools,
24
TPM Embedded Security Chip 1.2, HP Fingerprint
Sensor, Pre-Boot Security, HP SpareKey,
25
HP Disk Sanitizer,
26
Drive Encryption for HP ProtectTools, Credential Manager for HP ProtectTools, Face
Recognition for HP ProtectTools,
27
File Sanitizer for HP ProtectTools,
26
Smart Card Reader, Intel® AT (requires a Computrace subscription)(select
Models),
28
Device Access Manager with Just in Time Authentication or One Time Password
7
(DigitalPass), Secure Erase, DriveLock, Automatic DriveLock,
Password Manager for HP ProtectTools, Privacy Manager for HP ProtectTools, security lock slot Optional: Computrace,
7,29
HP Privacy Filter
7
Dimensions (w x d x h)
13.31 x 9.11 x 1.25 in (at front); 33.8 x 23.1 x 3.2 cm (at front)
Weight
Starting at 4.96 lb (2.25 kg) with SSD and weight saver; 5.27 lb (2.39 kg) with SSD and optical drive (weight will vary by conguration)
Power
20
9-cell (100 WHr) Lithium-Ion battery,
30
6-cell (62 WHr) Lithium-Ion battery,
30
6-cell (55 WHr) HP Long Life Battery (3-year),
30
optional HP ST09
Extended Life Notebook Battery (73 WHr),
7,30
optional HP BB09 Ultra Extended Life Notebook Battery (100 WHr),
7,30
90W HP Smart AC Adapter, HP Fast
Charge
31
Expansion Solutions
7
HP 90W Docking Station, HP 120W Advanced Docking Station, HP USB Docking Station 2.0, HP Essential USB 2.0 Port Replicator, HP Dual Hinge
Notebook Stand, HP Display & Notebook Stand, HP Adjustable Display Stand, HP Adjustable Dual Display Stand
Warranty
Limited 3-year, 1-year and 90-day warranty options available, depending on country, 1-year limited warranty on primary battery. Optional
HP Care Pack Services
7
are extended service contracts which go beyond your standard warranties.
32
For more details, visit hp.com/go/lookuptool.
HP recommends Windows
®
7.
2

HP EliteBook 8470w Specifications

General

Bus type	DMI
Stepping	E1
Tjunction	105 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-3630QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	PGA988
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	24
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	128 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display diagonal	14 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
On-board graphics card ID	0x166
Discrete graphics card model	AMD FirePro M2000
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Intel segment tagging	Enterprise
Audio system	SRS Premium Sound PRO
Number of built-in speakers	2
Wi-Fi standards	802.11a, 802.11b, 802.11g
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Keyboard layout	-
Pointing device	Touchpad
Bundled software	Microsoft Office Starter (Windows 7)\\r HP Recovery Manager\\r HP Performance Advisor\\r HP Support Assistant\\r HP ProtectTools Security Manager\\r HP ProtectTools for Central Management\\r HP Hotkey Support\\r HP Peak Power Manager\\r HP Power Assistant (Windows 7)\\r HP Wireless Hotspot (Windows 8)\\r HP Connection Manager (Windows 7)\\r Adobe Flash Player (Windows 7)\\r Windows Defender\\r Microsoft Security Essentials (Windows 7)\\r PDF Complete Special Edition\\r Roxio Secure Burn (Windows 7)\\r Roxio MyDVD Business 2010 (Windows 7)\\r Winzip Basic (Windows 7)\\r HP SoftPaq Download Manager
Recovery operating system	Windows 7 Professional
Operating system installed	Windows 8 Pro
Form factor	Clamshell
Product type	Laptop
Product color	Gray
Country of origin	China
Processor code	SR0UX
Processor ARK ID	71459
Processor package size	37.5 x 37.5 (rPGA988B) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery capacity	100 Wh
Battery life (max)	5.45 h
Number of battery cells	9
AC adapter power	90 W
Cable lock slot type	Kensington

Weight and Dimensions

Depth	231.3 mm
Width	338 mm
Height	31.8 mm
Weight	2250 g
