Display assembly subcomponents
Item Component Spare part number
(1) Bezel 821183-001
Hinge covers (left and right) 821187-001 (Hinge Kit)
(2a) Left hinge cover
(2b) Right hinge cover
Hinge Kit (includes left and right hinges) 821187-001
(3a) Left hinge
(3b) Right hinge
(4) Microphone module 920485-001
(5) Webcam module (includes microphone) 800575-020
(6) Display/webcam cable (HD/FHD and UHD) 914749-001 (Cable Kit)
(7) WLAN antenna (spared with display enclosure)
22 Chapter 3 Illustrated parts catalog
