Fingerprint reader assembly
Description Spare part number
Fingerprint reader assembly (includes cable) 849912-001
Before removing the ngerprint reader assembly, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is o or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet, and
then unplugging the AC adapter from the computer.
4. Remove the bottom cover (see Bottom cover on page 34).
5. Remove the battery (see Battery on page 38).
6. Remove the keyboard (see Keyboard on page 50).
7. Remove the internal base plate (Internal base plate on page 53).
Remove the ngerprint reader assembly:
1. Position the computer upright and open all the way.
2. Disconnect the ngerprint reader board cable from the system board (1).
3. Close the computer, and then position the computer upside down.
4. Remove the Mylar cover from atop the ngerprint reader assembly (2).
5. Slide the bracket toward the right, and then lift it from the computer (3).
6. Remove the ngerprint reader board and cable assembly from the computer (4).
Reverse this procedure to install the ngerprint reader assembly.
58 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
