15. On the back of the display panel, lift the tape from atop the connector (2), and then disconnect the
display cable from the rear of the panel (3).
The raw display panel is available using the following spare part numbers:
NOTE: Display panel kits include panel, touch module (as applicable), display cable, and interior panel
bezel.
FHD panel, non-touch: L16640-001
FHD panel, touch: L16641-001
FHD panel, touch, privacy: L18315-001
QHD panel: L16642-001
78 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
