HP EliteBook 8540w - 39.6-CM (15.6-In) HD Display Specifications

Metric U.S.
Nonoperating 1.50 g zero-to-peak, 10 Hz to 500 Hz, 0.5 oct/min sweep rate
NOTE: Applicable product safety standards specify thermal limits for plastic surfaces. The computer operates well within
this range of temperatures.
39.6-cm (15.6-in) HD display specifications
Metric U.S.
Dimensions
Height 21.0 cm 8.25 in
Width 35.9 cm 14.15 in
Diagonal 39.6 cm 15.6 in
Surface treatment Anti-glare
Contrast ratio 300:1 (typical)
Refresh rate 60 Hz
Brightness 200 nits (typical)
Pixel resolution
Pitch 0.252 mm
Format 1366 × 768
Configuration RGB stripe
Backlight LED
PPI 101 ppi
Viewing angle +/-30 horizontal (minimum), +/–10° vertical (minimum)
30/30/20/10 (Left/Right/Down/Up) (minimum) or
45/45/35/25 (Left/Right/Down/Up) (typical)
114 Chapter 6 Specifications
