Requirements for specific countries and regions
Country/region Accredited agency Applicable note number
Australia EANSW 1
Austria OVE 1
Belgium CEBC 1
Canada CSA 2
Denmark DEMKO 1
Finland FIMKO 1
France UTE 1
Germany VDE 1
Italy IMQ 1
Japan METI 3
The Netherlands KEMA 1
Norway NEMKO 1
The People's Republic of China CCC 5
South Korea EK 4
Sweden SEMKO 1
Switzerland SEV 1
Taiwan BSMI 4
The United Kingdom BSI 1
The United States UL 2
1. The flexible cord must be Type HO5VV-F, 3-conductor, 1.0-mm² conductor size. Power cord set fittings (appliance
coupler and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region
where it will be used.
2. The flexible cord must be Type SPT-3 or equivalent, No. 18 AWG, 3-conductor. The wall plug must be a two-pole
grounding type with a NEMA 5-15P (15 A, 125 V) or NEMA 6-15P (15 A, 250 V) configuration.
3. The appliance coupler, flexible cord, and wall plug must bear a “T” mark and registration number in accordance with the
Japanese Dentori Law. The flexible cord must be Type VCT or VCTF, 3-conductor, 1.00-mm² conductor size. The wall
plug must be a two-pole grounding type with a Japanese Industrial Standard C8303 (7 A, 125 V) configuration.
4. The flexible cord must be Type RVV, 3-conductor, 0.75-mm² conductor size. Power cord set fittings (appliance coupler
and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it
will be used.
5. The flexible cord must be Type VCTF, 3-conductor, 0.75-mm² conductor size. Power cord set fittings (appliance coupler
and wall plug) must bear the certification mark of the agency responsible for evaluation in the country or region where it
will be used.
Requirements for specific countries and regions 139

Table of Contents

Other manuals for HP EliteBook 8540w

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8540w and is the answer not in the manual?

HP EliteBook 8540w Specifications

General IconGeneral
Bus typeDMI
SteppingB1
Tjunction100 °C
Processor cache8 MB
Processor cores4
Processor modeli7-840QM
System bus rate2.5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-800 Mobile Series
Processor socketSocket 988
Processor threads8
Processor codenameClarksfield
Processing Die size296 mm²
Processor frequency1.86 GHz
Processor cache typeSmart Cache
Processor lithography45 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.2 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8
Thermal Design Power (TDP)45 W
CPU multiplier (bus/core ratio)14
Maximum number of PCI Express lanes16
Number of Processing Die Transistors774 M
Motherboard chipsetIntel® QM57 Express
HDD speed7200 RPM
HDD interfaceSATA
Optical drive type-
Card reader integratedYes
Total storage capacity500 GB
Number of HDDs installed1
Display diagonal15.6 \
Native aspect ratio16:9
Modem speed56 Kbit/s
Power supply typeAC/DC
Intel segment taggingEnterprise
Compliance industry standardsIEEE802.3, IEEE802.3u, IEEE802.3ab
Internal memory4 GB
Memory clock speed1333 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Number of built-in speakers2
Pointing deviceTouchpad
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version2.1+EDR
Cabling technology10/100/1000Base-T(X)
Networking featuresGigabit Ethernet
Operating system installedWindows 7 Professional
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity0
AC adapter power150 W
Battery capacity73 Wh
Product colorBlack, Silver
Country of originChina
Processor ARK ID43125
Processor package size37.5 x 37.5 mm
Supported instruction setsSSE4.2
Intel® Turbo Boost Technology1.0
Physical Address Extension (PAE)36 bit
Weight and Dimensions IconWeight and Dimensions
Depth251.5 mm
Width373.5 mm
Height32.4 mm
Weight2950 g
