Keyboard
NOTE: For a detailed list of available keyboards, see Sequential part number listing on page 41.
Description Spare part number
Keyboard for use in model 6560b without a pointing stick 641180-xxx
Keyboard for use in model 6560b with a pointing stick 641179-xxx
Keyboard for use in model 8560p 641181-xxx
Before removing the keyboard, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet,
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 60).
5. Remove the bottom door (see
Bottom door on page 66).
6. Remove the fan (see
Fan on page 87).
7. Remove the heat sink (see
Heat sink on page 89).
Remove the keyboard:
1. Position the computer upside-down with the battery bay toward you.
2.
Loosen the three Phillips captive screws that secure the keyboard to the computer.
Component replacement procedures
95
