HP EliteBook 8560p User Manual

Bluetooth module
NOTE: The Bluetooth module spare part kit does not include a Bluetooth module cable. The Bluetooth
module cable is included in the Cable Kit, spare part number 646968-001 for use in 6560b models
and 641188-001 for use in 8560p models. See
Cable Kit on page 38 for more Cable Kit spare part
number information.
Description Spare part number
Bluetooth module 537921-001
Before removing the Bluetooth module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet,
and then unplugging the AC adapter from the computer.
4.
Remove the battery (see
Battery on page 60).
5. Remove the bottom door (see
Bottom door on page 66).
Remove the Bluetooth module:
1. Position the computer upside-down with the front toward you.
Component replacement procedures
83

HP EliteBook 8560p Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Display	LED
Expansion slots	1 Express Card/54; 1 lettore di Smart Card; 1 SD/MMC
Infrared data port	No
HDD controller type	Unità a stato solido
Graphics card family	AMD
Intel segment tagging	Enterprise
Bundled software	Roxio My DVD 2010 SE Microsoft Office 2010 Norton Internet Security 2011
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Motherboard chipset	Intel® QM67 Express
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 90 %
Display diagonal	15.6 \
Display resolution	- pixels
Audio system	SRS HD
Audio included	Audio ad alta definizione SRS, altoparlanti stereo integrati, uscita stereo cuffie/linea, ingresso microfono stereo, microfono integrato (array doppio microfono con webcam opzionale)
Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-2620M
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.4 GHz
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	27
Maximum number of PCI Express lanes	16
Pointing device	Touchpad + Pointing Stick
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
AC adapter power	65 W
Battery capacity	55 Wh
Number of battery cells	6
Sustainability certificates	ENERGY STAR
On-board graphics card ID	0x116
Discrete graphics card model	AMD Radeon HD 6470M
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz
Processor code	SR041
Processor ARK ID	52231
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Country of origin	China

Weight and Dimensions

Depth	250 mm
Width	374 mm
Height	34 mm
Weight	2730 g
