HP EliteBook 8570w

6. Remove the hard or optical drive from the upgrade bay (see Replacing a drive in the upgrade
bay on page 33).
7. Remove the keyboard:
a. With the computer upside down, loosen the three captive keyboard screws (1) on the
bottom of the computer.
b. Release the keyboard by pressing down on the keyboard release cut-out (2).
c. Turn the computer right-side up and gently release the tabs along the top edge of the
keyboard (3). Then rest the keyboard on the TouchPad.
NOTE: Do not disconnect the keyboard cable. To avoid disconnecting the keyboard
cable, do not pull the keyboard away from the computer.
Replacing a drive in the upgrade bay 39
