HP EliteBook 8570w

11. Remove the four screws (1) on the hard drive bracket and remove the hard drive bracket (2).
NOTE: The new hard drive may have a bracket attached. If a bracket is not included, reverse
this procedure to place the bracket onto the new hard drive.
Installing a hard drive
To install the hard drive:
1. Lower the hard drive (1) into the hard drive bay.
2. Pull the hard drive tab (2) to the left until the hard drive is fully seated
Replacing or upgrading the hard drive 31
