Base enclosure

Description Spare part number

Base enclosure 702863-001

Before removing the base enclosure, follow these steps:

1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the

computer on, and then shut it down through the operating system.

2. Disconnect the power from the computer by unplugging the power cord from the computer.

3. Disconnect all external devices from the computer.

4. Remove the battery (see

Battery on page 41), and then remove the following components:

a. Hard drive cover (see

Hard drive cover on page 47)

b. Hard drive (see

Hard drive/SSD drive on page 48)

c. Service cover (see

Service cover on page 53)

d. Keyboard (see

Keyboard on page 60)

Remove the base enclosure:

1. Close the computer and position it upside down.

2. Remove the WLAN (1) and WWAN (2) antennas from the routing path (3) in the base enclosure.

Component replacement procedures
