Remove the smart card board:
1. Remove the Phillips PM2.0×2.5 broadhead screw (1) that secures the board to the computer.
2. Rotate the board upward (2) at an angle, and then remove it from the computer (3).
Reverse the removal procedures to install the smart card board.
76 Chapter 4 Removal and replacement procedures
