IN/OUT Headphone/
microphone jacks
Black PWR System board
power connector
White
USB USB 3.0 and USB
2.0 ports
Black FRONTUSB3.0 Front USB 3.0 port
connector
Blue
VGA/COMA Display connector/
serial port
Black SPKR Speaker connector White
DISPLAYPORT DisplayPort
connector
Silver MEDIA3.0 USB 3.0 Device,
such as a USB 3.0
Media Card Reader
Black
RJ45/USB Network jack/USB
2.0 ports
Silver SATA0 Primary hard drive
connector
Dark blue
PS2 Mouse/keyboard
connectors
Green/
purple
SATA1 Any SATA Device
other than the
Primary Hard Drive
Light blue
PAR Parallel port
connector
Black SATA2 Any SATA Device
other than the
Primary Hard Drive
Light blue
COMB Serial port
connector
Black MEDIA USB 2.0 Device,
such as a USB 2.0
Media Card Reader
Black
PWRCPU Power connector White FRONT USB Front I/O USB
connector
Yellow
XU1 Processor socket Silver PSWD System password
header/jumper
Black/
green
CPUFAN Processor fan
connector
White CMOS CMOS reset button Yellow
CLINK C-Link connector Black XBT RTC battery socket Black
DIMM4 Memory socket –
Channel A
White HSENSE Hood sensor
connector
White
DIMM3 Memory socket –
Channel A
Black HLCK Hood lock
connector
Black
DIMM2 Memory socket –
Channel B
White FRONT AUD Front I/O asseembly
audio connector
Blue
System board callouts
