Item Component Spare part number
Home button board (not illustrated, includes bracket) 718663-001
Display Cable Kit, includes: 718758-001
(2a) TouchScreen cable
(2b) Display LVDS cable
Webcam Kit, includes: 709455-001
(3a) Rear-facing webcam
(3b) Front-facing webcam
Microphone Kit, includes: 709454-001
(4a) Left microphone
(4b) Right microphone
Bracket Kit, includes: 718834-001
(5a) Communications bracket
(5b) Volume button board bracket
(5c) Docking connector bracket
Cable Kit, includes: 709459-001
(6a) Communications cable
(6b) Power button board cable
(6c) WLAN ribbon cable
(6d) Docking connector cable
Antenna Kit, includes: 709451-001
(7a) GPS auxiliary antenna cable
(7b) WWAN auxiliary antenna cable
(7c) WLAN auxiliary and main antenna cables
NFC antenna cable (not illustrated)
(8) WWAN module:
HP hs3120 HSPA+ Mobile Broadband Module 714653-005
HP hs3121 HSPA+ Mobile Broadband Module 696218-005
HP hs3124 HSPA+ Mobile Broadband Module 714655-005
(9) Power button board (includes cable)
For use only on computer models equipped with the Windows 8 Professional
operating system
724350-601
For use only on computer models equipped with the Windows 8 Standard
operating system
724350-501
10 Chapter 3 Illustrated parts catalog
