Item Component Spare part
number
(9) Power Connector
For use with HP ENVY 15 Notebook PC computer models 762507-001
For use with HP ENVY 17 Notebook PC computer models 763699-001
(10) Memory module (PC3L, 12800, 1600-MHz, shared):
4 GB 691740-005
8 GB 693374-005
(11) Fan 763700-001
(12) RTC battery 697917-001
(13) 256 GB mSATA solid-state drive MLC (not pictured) available on select models. For specific hard drives,
see Mass Storage Devices.
(14) Heat sink (includes replacement thermal material):
For use only on computer models with UMA memory 19 W available only on Pavilion 15 computer
models
763701-001
For use only on computer models with UMA memory 47 W 763702-001
For use only on computer models with discrete memory 19 W on HP Pavilion 17 computer models only 763703-001
For use only on computer models with discrete memory 35 W HP Pavilion 17 computer models only 763704-001
(15) Display Cable
For specific Cables, see
Display assembly subcomponents on page 18.
(16) Speaker Kit (includes left and right front speakers and cables)
For HP ENVY 17 Notebook PC computer models 763717-001
For HP ENVY 15 Notebook PC computer models 762502-001
(17) Subwoofer (select models only)
For HP ENVY 17 Notebook PC computer models 763716-001
For HP ENVY 15 Notebook PC computer models 763788-001
(18) Hard drive for specific hard drives, see Mass Storage Devices.
(19) 4-cell, 41 WHr, 2.8A H Li-ion battery 756743-001
4-cell, 48 WHr, 2.3 AH Li-ion battery 756745-001
(20) Optical drive: for specific hard drives, see Mass Storage Devices.
(21) Base enclosure:
For use on HP ENVY 17 Notebook PC computer models and computer models 763695-001
For use on HP ENVY 17 Notebook PC computer models in natural silver 774554-001
For use on HP ENVY 15 Notebook PC computer models 763570-001
For use on HP ENVY 15 Notebook PC computer models equipped with a 3D camera 794976-001
(22) Base enclosure caps (Included in the plastics kit)
Computer major components 17
