Heat sink
Description Spare part number
For use only on computer models with UMA memory 19 W for use with HP ENVY 17 Notebook PC
computer models
763701-001
For use only on computer models with UMA memory 47 W for use with HP ENVY 15 Notebook PC
computer models and for use with HP ENVY 17 Notebook PC computer models
763702-001
For use only on computer models with discrete memory 19 W for use with HP ENVY 17 Notebook PC
computer models
763703-001
For use only on computer models with discrete memory 35 W for use with HP ENVY 17 Notebook PC
computer models
763704-001
NOTE: To properly ventilate the computer, allow at least 7.6 cm (3 in) of clearance on the left side of
the computer. The computer uses an electric fan for ventilation. The fan is controlled by a temperature
sensor and is designed to turn on automatically when high temperature conditions exist. These conditions
are affected by high external temperatures, system power consumption, power management/battery
conservation configurations, battery fast charging, and software requirements. Exhaust air is displaced
through the ventilation grill located on the left side of the computer.
Before removing the heat sink, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 37),
5. Remove the optical drive (see
Optical drive on page 38).
6. Remove the top cover from the base enclosure (see
Base enclosure on page 41).
7. Remove the WLAN module (see
WLAN module on page 55).
8. Remove the subwoofer (see
Subwoofer on page 60).
9. Remove the system board (see
System board on page 63).
10. Remove the fan (see
Fan on page 74).
Remove the heat sink:
▲
Loosen the seven captive screws in the order listed on the heat sink (1), and then remove the heat sink
(2).
NOTE: The heat sink may vary by computer model and may have a different number of screws. The
heat sink is marked with the order the screws should be removed in. Follow the order shown.
Component replacement procedures 75
