HP ENVY Disassembly Instructions

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
refractory ceramic fibers
0
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Screwdriver
#1
Description #2
Description #3
Description #4
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove battery module
2. Dis-fasten ODD screw*
3. Remove ODD
4. Remove BASE rubber feet*2
5. Dis-fasten BASE Cap screw*2
6. Disassemble BASE Cap*2
7. Dis-fasten BASE screw*15
8. Disassemble KB Deck
9. Pull out FFC*3 (Power, Touchpad, Fingerprint)
10. Pull out FFC*1 (USB)
11. Dis-fasten daughter boards screw*1 (Power)
12. Remove daughter boards*2 (Power, USB)
13. Pull out wire cable connectors*2 (LCD, DC cable)
14. Pull out wire cable*2 (speaker, woofer)
15. Pull out HDD assembly
16. Dis-fasten DC BKT screw*2
17. Remove DC BKT
18. Dis-connect antenna cable connector
19. Remove WLAN module
20. Dis-fasten motherboard screw*5
21. Remove motherboard
22. Dis-fasten Speaker R&L screw*1
23. Remove speaker -L & -R
24. Pull out fan cable
25. Dis-fasten Fan screws*1
26. Remove Fan module
27. Dis-fasten thermal module screw*7
28. Remove thermal module
29. Pull out DC cable connector
30. Dis-fasten Hinge screw*5
31. Remove hinge-up
32. Remove LCD Bezel screw pad*2
33. Dis-fasten LCD Bezel screws*2

HP ENVY Specifications

General

Bus type	DMI
Stepping	D2
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-2630QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	Socket 988
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM67 Express
HDD speed	5400 RPM
HDD capacity	750 GB
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1500 GB
Number of HDDs installed	2
Display diagonal	17.3 \
Native aspect ratio	16:9
Display number of colors	16.78 million colors
Type	PC
Power supply type	AC/DC
Power requirements	100 - 240V
AC adapter included	Yes
Wireless technology	Wi-Fi
Graphics card family	AMD
Compliance industry standards	802.11a/b/g/n
Maximum internal memory (64-bit)	16 GB
Memory slots	4x SO-DIMM
Internal memory	8 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
On-board graphics card ID	0x116
Discrete graphics card model	AMD Radeon HD 6850M
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Audio system	HD
Keyboard layout	AZERTY
Pointing device	Touchpad + Scroll zone
Networking type	10/100/1000
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Home Premium
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Password protection type	BIOS, HDD
Battery life (max)	2.25 h
Number of battery cells	6
AC adapter power	120 W
Sustainability certificates	EPEAT Silver
Product color	Black, Silver
Country of origin	China
Processor code	SR02Y
Processor ARK ID	52219
Processor package size	37.5 x 37.5 (rPGA998) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	275 mm
Width	416 mm
Height	38.7 mm
Weight	3410 g
